10-7
155507-1CD
RE-CSO-A037
DX100
10 Handling Application
10.2 Registering Instructions
10.2 Registering Instructions
10.2.1 HAND Instruction
This instruction turns ON/OFF the gripper valve signal and controls the
tool.
1. Select {JOB} under the main menu.
2. Select {JOB}.
3. Press [TOOL 1 ON/OFF] or [TOOL 2 ON/OFF].
– “HAND 1 ON” is displayed if [TOOL 1 ON/OFF] is pressed; “HAND 2
ON” is displayed if [TOOL 2 ON/OFF] is pressed in the input buffer
line.
If “HAND” is selected after pressing [INFORM LIST], “HAND 1 ON”
is displayed.
– To register the instruction shown in the input buffer line without
editing, press [INSERT] and then press [ENTER].
4. Select the gripper number and edit.
– The input line is displayed.
– Input the gripper number with the Numeric keys, and press
[ENTER].
5. Select the gripper output status and edit.
– If the UP or DOWN ARROW cursor is pressed together with
[SHIFT], “ON” and “OFF” are alternately displayed.
– If no settings are to be made for other additional items, press
[INSERT] and then press [ENTER]. The HAND instruction is
registered.
To Next Page
