YASKAWA DX100 Operator's Manual

3 Teaching
3.9 Other Job-editing Functions
3-77
155507-1CD
RE-CSO-A037
DX100
3.9.4 User Variables
User variables are used for jobs to store counters, calculation results or
input signals. Since the same user variable can be used in multiple jobs,
save the numerical values as common references for the jobs and the
user variables are maintained even when the power is turned OFF.
User variables have the following applications:
• Controlling of the number of workpieces
• Controlling of the number of jobs
• Sending/receiving of information between jobs
The data formats for user variables are described in the following table:
Table 3-5: User Variables
Data
Format
Variable No.
(pcs)
Functions
Byte Type B000 to B099 
(100)
Range of storable values is from
0 to 255. 
Can store I/O status. 
Can perform logical operations
(AND, OR, etc.)
Integer
Type
1000 to 1099
(100)
Range of storable values is from -
32768 to 32767.
Double
Precision
Integer
Type
D000 to D099
(100)
Range of storable values is from -
2147483648 to 2147483647.
Real Type
R000 to R099
(100)
Range of storable values is from -
3.4E+38 to 3.4E38. 
Accuracy: 1.18E-38 < x  3.4E38
Character
Type
S000 to S099
(100)
Maximum storable number of
characters is 16.
Position
Type
P000 to P127
(128)
Can store position data in pulse
form or in XYZ form.
XYZ type variable can be used as
target position data for move
instructions, and as incremental
values for parallel shift
instructions.
BP000 to BP127
(128)
EX000 to EX127
(128)
160 of 554

YASKAWA DX100 Specifications

General

Programming Language	Inform III
Compatible Robots	Motoman robots
Operating Temperature	0-45°C
Humidity	20-80% RH (non-condensing)
Protection Class	IP20
Interface	Ethernet
Safety Standards	ANSI/RIA R15.06-1999
Pendant	Available
I/O Capacity	1024 inputs / 1024 outputs
Storage Temperature	-10-60°C
