YASKAWA DX100 Operator's Manual

6 Convenient Functions
6.8 Simple Menu Function
6-76
155507-1CD
RE-CSO-A037
DX100
6.8 Simple Menu Function
1)
6.8.1 Simple Menu
This function enables users to create “USER DEFINITION” menu by
registering the layouts (screen dividing patterns and screen to be
displayed) on the general-purpose display area.
Eight layout patterns can be registered to the user definition menu at
maximum. 
The registered layout patterns can be easily called up with the buttons of
simple menu.
1 Simple menu function is available in DS1.50-00 version or later.
316 of 554

YASKAWA DX100 Specifications

General

Programming Language	Inform III
Compatible Robots	Motoman robots
Operating Temperature	0-45°C
Humidity	20-80% RH (non-condensing)
Protection Class	IP20
Interface	Ethernet
Safety Standards	ANSI/RIA R15.06-1999
Pendant	Available
I/O Capacity	1024 inputs / 1024 outputs
Storage Temperature	-10-60°C
