YASKAWA DX100 Operator's Manual

3 Teaching
3.5 Modifying Jobs
3-49
155507-1CD
RE-CSO-A037
DX100
3.5.6 JOB CAPACITY Window
1. Select {JOB} under the main menu.
2. Select {JOB CAPACITY}.
A. NUMBER OF JOBS
Displays the total number of jobs currently registered in the memory of
DX100.
B. USED MEMORY
Displays the total amount of memory used in the DX100.
C. STEPS
Displays the total number of used steps.
D. EDITING BUFFER
Displays editing buffer use.
B
A
C
D
132 of 554

YASKAWA DX100 Specifications

General

Programming Language	Inform III
Compatible Robots	Motoman robots
Operating Temperature	0-45°C
Humidity	20-80% RH (non-condensing)
Protection Class	IP20
Interface	Ethernet
Safety Standards	ANSI/RIA R15.06-1999
Pendant	Available
I/O Capacity	1024 inputs / 1024 outputs
Storage Temperature	-10-60°C
