3 Teaching
3.5 Modifying Jobs
3.5.4.1 Switching the Address Area
Able to switch a state of the display (to hide or show) of the following
numbers in the address area.
• Step numbers
• Tool numbers in the each step
1. Select the {JOB} under the main menu.
2. Select {JOB CONTENT}.
– Job content appears.
3. Select {DISPLAY} in the menu area.
– A pull down menu appears.
4. Select {ENABLE STEP NO}.
– Step numbers appear in the address area.
– In the pull down menu, {ENABLE STEP NO} changes to 
{ ✻ ENABLE STEP NO}.
STEP NO.
