3.5.4 JOB CONTENT Window
1. Select {JOB} under the main menu.
2. Select {JOB}.
– The JOB CONTENT window appears.
–  (Left) : The cursor is moved to the address area.
–  (Right): The cursor is moved to the instruction area.
A. Address Area
Displays the line numbers, the step numbers and the tool numbers
which are registered in the each step.
B. Instruction Area
Displays instructions, additional items, and comments. Line editing is
possible.
B
A
