YASKAWA DX100 - Screen Descriptions

1-17
155507-1CD
RE-CSO-A037
DX100
1 Introduction
1.2 Programming Pendant
1.2.5 Screen Descriptions
• The menu displayed in the programming pendant is denoted with { }. 
The above menu items are denoted with {DATA}, {EDIT}, {DISPLAY},
AND {UTILITY}.
• The window can be displayed according to the view desired.
Full Window View
Upper Window View
Middle Window View
Lower Window View
