10-9
155507-1CD
RE-CSO-A037
DX100
10 Handling Application
10.2 Registering Instructions
10.2.2 HSEN Instruction
This instruction monitors the various inputs used for handling and outputs
the monitor result as a variable.
1. Select {JOB} under the main menu.
2. Select {JOB}.
3. Press [INFORM LIST].
4. Select the HSEN instruction.
– The HSEN instruction is displayed in the input buffer line.
– To register the instruction shown in input buffer line without editing,
press [INSERT] and then press [ENTER].
5. Select the sensor number and edit.
– The input line is displayed.
– Input the sensor number with the Numeric keys, and press
[ENTER].
6. Select the sensor input status and edit.
– If the UP or DOWN ARROW cursor is pressed together with
[SHIFT], “ON” and “OFF” are alternately displayed.
– If no settings are to be made for other additional items, press
[INSERT] and then press [ENTER]. The HSEN instruction is
registered.
7. Edit the signal waiting time.
– If inserting a signal waiting time, select “HSEN.”
The DETAIL EDIT window appears.
To Next Page
