YASKAWA DX100 Operator's Manual

8 Parameter
8.5 Parameters according to Status I/O
8-41
155507-1CD
RE-CSO-A037
DX100
8.5.0.3 S4C016 to S4C031: PARITY OF USER OUTPUT GROUPS
These parameters specify whether the output group instruction is
executed with parity check (even parity).
Parity bits are set as the highest level bits of each output group. For
example, if OG#01 is specified with parity and DOUT OG# (1) 2 is
executed, the result will be 00000010 if 2 is binary converted. Since there
will be only one bit (odd) ON at this time, the parity bit (highest level bit)
will be set to ON and 10000010 (130) will be output to OG# (1).
As in the case of a variable such as DOUT OG# (1) B003 parity bits are
added to the contents of the variable data. However, if the contents of the
variable exceed 127, as in the case of DOUT OG# (1) 128, an alarm will
occur. Remains unchanged if no parity check is specified.
d15 d0
OG#01
OG#02
OG#03
OG#04
OG#05
OG#06
OG#07
OG#08
OG#09
OG#10
OG#11
OG#12
OG#13
OG#14
OG#15
OG#16
S4C016
d15 d0
OG#17
OG#18
OG#19
OG#20
OG#21
OG#22
OG#23
OG#24
OG#25
OG#26
OG#27
OG#28
OG#29
OG#30
OG#31
OG#32
S4C017
d15 d0
OG#33
OG#34
OG#35
OG#36
OG#37
OG#38
OG#39
OG#40
OG#41
OG#42
OG#43
OG#44
OG#45
OG#46
OG#47
OG#48
S4C018

472 of 554

YASKAWA DX100 Specifications

General

Programming Language	Inform III
Compatible Robots	Motoman robots
Operating Temperature	0-45°C
Humidity	20-80% RH (non-condensing)
Protection Class	IP20
Interface	Ethernet
Safety Standards	ANSI/RIA R15.06-1999
Pendant	Available
I/O Capacity	1024 inputs / 1024 outputs
Storage Temperature	-10-60°C
