YASKAWA DX100 Operator's Manual

3 Teaching
3.9 Other Job-editing Functions
3-101
155507-1CD
RE-CSO-A037
DX100
3.9.12.3 Label Search
This function searches for the desired label and the instruction using that
label.
1. Select {EDIT}, {SEARCH} and “LABEL SEARCH”.
– The characters can be entered.
2. Input desired label name.
– For information on character input operation, refer to section 1.2.6
“Character Input Operation” on page 1-18.
– At this time, search can be conducted by entering any one character
of the label. For example, to search for the “START” label, enter
only “S”, and the search can be done.
3. Press [ENTER].
– The cursor is moved to the desired label and the window appears.
184 of 554

YASKAWA DX100 Specifications

General

Programming Language	Inform III
Compatible Robots	Motoman robots
Operating Temperature	0-45°C
Humidity	20-80% RH (non-condensing)
Protection Class	IP20
Interface	Ethernet
Safety Standards	ANSI/RIA R15.06-1999
Pendant	Available
I/O Capacity	1024 inputs / 1024 outputs
Storage Temperature	-10-60°C
