1.2.4.2 General-purpose Display Area
On the general-purpose display area, various settings and contents such
as jobs and characteristics files can be displayed and edited.
The operation buttons are also displayed at the bottom of the window
according to the window contents.
• To move the cursor to the operation button, press [AREA] + DOWN
cursor key.
• To move the cursor to the general-purpose display area, press
[AREA] + UP cursor key or press [CANCEL].
• To move the cursor between the operation buttons, use the RIGHT
or LEFT cursor key.
• To execute the operation button, move the cursor to the button and
press [SELECT].
EXECUTE :
Continues operation with the displayed contents.
CANCEL :
Cancels the displayed contents and returns to the previous window.
COMPLETE :
Completes the setting operation displayed on the general-purpose display
area.
STOP :
Stops operation when loading, saving, or verifying with an external memory
device.
RELEASE :
Releases the overrun and shock sensor function.
RESET :
Resets an alarm. (Cannot reset major alarms.)
PAGE :
Jumps to the appropriate page if the page can be switched.
• When the page can be switched by specifying the page number, the
following input box appears when “DIRECT PAGE” is selected. Directly
type the desired page number and press [ENTER].
• When the page can be switched by selecting an item, the following
selection list appears when “DIRECT PAGE” is selected. Select a desired
item using the UP and DOWN cursor key and press [ENTER].
JUMP TO:
PAGE
Operation buttons
General-purpose
display area
To Next Page
