9 General Purpose Application
9.2 Operation for Tool Control
4. Press [INSERT].
5. Press [ENTER].
9.2.3.2 CALL Instruction
This instruction calls a reserved job TOOLONxx or TOOLOFxx. The
function keys for registration are [TOOLON JOB] and [TOOLOF
JOB].
1. Select {JOB} under the main menu.
2. Select {JOB}.
3. Press [TOOLON JOB] or [TOOLOF JOB].
– The CALL instruction is displayed in the input buffer line.
4. Select the job name.
– The JOB LIST window appears.
5. Press [SELECT].
– The window for character input appears. 
The job name can now be changed. Modify the job name and press
[ENTER].
6. Press [INSERT].
7. Press [ENTER].
9.2.3.3 WVON Instruction
This instruction starts the weaving motion. Specify conditions in the
weaving condition file when registering the WVON instruction
.
1. Select {JOB} under the main menu.
2. Select {JOB}.
3. Press [INFORM LIST].
4. Select the WVON instruction.
– The WVON instruction is displayed in the input buffer line.
– To register the instruction displayed in the input buffer line without
editing, press [INSERT] and then press [ENTER].
5. Select the file number and edit.
– The input line is displayed.
– Input weaving file number using the Numeric keys and press
[ENTER]. (In the following example, 2 is entered.)
6. Press [INSERT].
7. Press [ENTER].
CALL JOB:TOOLON
WVON WEV#(1)
Weaving_file_no.=
WVON WEV#( ) ON
WVON WEV#( 2 )
