YASKAWA DX100 Operator's Manual

6 Convenient Functions
6.8 Simple Menu Function
6-82
155507-1CD
RE-CSO-A037
DX100
2. Press {EDIT} button.
– “USER DEFINITION” menu closes.
– “USER DEFINITION MENU” window appears on the active window
in the general-purpose display area.
6.8.4.2 Displaying “USER DEFINITION MENU” window Under Main Menu
Displays “USER DEFINITION MENU” window under main menu.
1. Select {SYSTEM INFO} under the main menu.
– {SYSTEM INFO} sub menu appears.
2. Select {USER DEFINITION}.
322 of 554

YASKAWA DX100 Specifications

General

Programming Language	Inform III
Compatible Robots	Motoman robots
Operating Temperature	0-45°C
Humidity	20-80% RH (non-condensing)
Protection Class	IP20
Interface	Ethernet
Safety Standards	ANSI/RIA R15.06-1999
Pendant	Available
I/O Capacity	1024 inputs / 1024 outputs
Storage Temperature	-10-60°C
