8-52
155507-1CD
RE-CSO-A037
DX100
8 Parameter
8.8 Hardware Control Parameters
8.8.0.2 S4C327 to S4C390: SETTING OF OPERATING RELAY NO.
Up to 64 output signals can be turned ON/OFF with the programming
pendant. The object relay No. is set in these parameters. Although it is
possible to set optional values for output No. 1 to 1024 in the parameters,
the following must be taken into consideration.
• Avoid setting duplicate numbers.
• The signal turned ON or OFF with the programming pendant is
operated again or remains unchanged until the instruction is
executed.
8.8.0.3 S4C391 to S4C454: OPERATING METHOD OF RELAYS
These parameters specify the operating method of output signals by the
programming pendant. The operating method can be specified for each
output signal.
8.8.0.4 S2C786 to S2C788: COOLING FAN ALARM DETECTION
This parameter specifies a detection for cooling fan 1 to 3 with alarm
sensor, connected to power ON unit.
Parameter Setting
Value
Operation of Output Signal
0
1
+
ON
ON/OFF with the key
ON while the key
is pressed
OFF if the key is
not pressed
ON
OFF
0 : No detection
1 : Detected with message display
2 : Detected with message and alarm display
