Page #453 background image
8-22
155507-1CD
RE-CSO-A037
DX100
8 Parameter
8.3 Mode Operation Setting Parameters
8.3.0.36 S2C395: SIGNAL NAME ALIAS FUNCTION
On the JOB CONTENT window, the name registered to the user input/
output signal number can be displayed as alias instead of the signal
number itself.
1. With this function valid, the confirmation dialog box “Register by name
(alias)?” is displayed when a signal (IN#(), OT#(), IG#(), OG#(),
IGH#(), OGH#()) is selected on the DETAIL EDIT window.
2. Select “YES” and the signal select window appears. Then select the
target signal of number and press [ENTER], and the registered name
is displayed instead of the signal number. However, if the signal
numbers name is not yet registered, it is displayed by number as
usual.
<Example> Registration of the name of user output OUT#0001 as
“OUTPUT 1”
In the case of DOUT instruction:
S2C395=0 : DOUT OT#(1) ON
S2C395=1 : DOUT OT#(OUTPUT 1) ON
Table 8-4: S2C395
Parameter Setting Value Valid/Invalid
0 Function invalid
1 Function valid
SUPPLE-
MENT
Select {IN/OUT} {UNIVERSAL INPUT/OUTPUT} to edit
signal names on the window. Up to 16 characters can be
entered as a signal name. However, when this function is
valid, if the content below is entered, the error message
shows and the name cannot be registered.
• The name already registered
• Letters beginning with a number
• Letters including the signs below:
( , ) , [ , ] , = , < , > , space, comma
• Letters beginning with “alphabets representing variables” +
“number”
<Example> B0..., I0..., BP1..., LEX2...
Alphabets representing variables: B, I, D, R,
S, P, BP, EX, PX, LB, LI LD, LR, LS, LP, LBP,
LEX, LPX
When the name begins with “ ‘ ”, it is regarded as a comment
and the same comment can be registered for two or more
signals. In this case, although this function is valid, the
number is displayed on the JOB CONTENT window instead
of the name.
<Example> Registration of the name of user output
OUT#0002 as “ ‘OUTPUT 2”
S2C395=0 : DOUT OT#(2) ON
S2C395=1 : DOUT OT#(2) ON
