YASKAWA DX100 Operator's Manual

7 External Memory Devices
7.3 Operation Flow
7-28
155507-1CD
RE-CSO-A037
DX100
7.3.0.3 Loading Data
To upload data from the external memory device to the memory of the
DX100, follow the procedure in the following.
 Loading a Job
1. Select {FD/PC CARD} under the main menu.
2. Select {LOAD}.
– The following window appears.
3. Select {JOB}.
– The job selection window appears.
NOTE
Data such as PARAMETER, SYSTEM DATA, I/O DATA,
and the batch data such as PARAMETER BATCH, BATCH
CMOS, ALL CMOS AREA, that include PARAMETER,
SYSTEM DATA, I/O DATA, contain the information specific
to each robot controller.
Those data are prepared as backup data for reloading into
the controller used for saving.
Loading the data from other controller may result in
destruction or loss of critical system information.
Take extra care for the saved data.
414 of 554

YASKAWA DX100 Specifications

General

Programming Language	Inform III
Compatible Robots	Motoman robots
Operating Temperature	0-45°C
Humidity	20-80% RH (non-condensing)
Protection Class	IP20
Interface	Ethernet
Safety Standards	ANSI/RIA R15.06-1999
Pendant	Available
I/O Capacity	1024 inputs / 1024 outputs
Storage Temperature	-10-60°C
