6 Convenient Functions

6.8 Simple Menu Function

6-80

155507-1CD

RE-CSO-A037

DX100

6.8.3 Calling Up of the Registered Layout

6.8.3.1 Calling up

Call up the registered layout with the following procedures.

1. Press [SIMPLE MENU] key or select {Simple Menu} button at the

lower-left on the display.

– “USER DEFINITION” menu appears.

2. Select and press a button on “USER DEFINITION” menu to display a

layout to be called up.

– “USER DEFINITION” menu closes.

– The selected layout appears on the general-purpose display area.

320 of 554
