YASKAWA DX100 Operator's Manual

3 Teaching
3.9 Other Job-editing Functions
3-81
155507-1CD
RE-CSO-A037
DX100
4. Move the cursor to the data of the variable.
– The characters can be directly typed.
5. Input the desired characters.
– For information on character input operation, refer to section 1.2.6
“Character Input Operation” on page 1-18.
6. Press [ENTER].
– The input characters are set to the variable on the cursor position.
164 of 554

YASKAWA DX100 Specifications

General

Programming Language	Inform III
Compatible Robots	Motoman robots
Operating Temperature	0-45°C
Humidity	20-80% RH (non-condensing)
Protection Class	IP20
Interface	Ethernet
Safety Standards	ANSI/RIA R15.06-1999
Pendant	Available
I/O Capacity	1024 inputs / 1024 outputs
Storage Temperature	-10-60°C
