YASKAWA DX100 Operator's Manual

4 Playback
4.1 Preparation for Playback
4-5
155507-1CD
RE-CSO-A037
DX100
 Calling from the MASTER JOB Window
1. Select {JOB} under the main menu.
2. Select {MASTER JOB}.
– The MASTER JOB window appears.
3. Press [SELECT].
– The selection dialog box appears.
4. Select {CALL MASTER JOB}.
– The master job is called, and the JOB CONTENT window (during
the teach mode), or the PLAYBACK window (during the play mode)
appears.
194 of 554

YASKAWA DX100 Specifications

General

Programming Language	Inform III
Compatible Robots	Motoman robots
Operating Temperature	0-45°C
Humidity	20-80% RH (non-condensing)
Protection Class	IP20
Interface	Ethernet
Safety Standards	ANSI/RIA R15.06-1999
Pendant	Available
I/O Capacity	1024 inputs / 1024 outputs
Storage Temperature	-10-60°C
