YASKAWA DX100 Operator's Manual

5 Editing Jobs
5.3 Modifying Job Names
5-8
155507-1CD
RE-CSO-A037
DX100
5. Press [ENTER].
– The confirmation dialog box appears.
– When “YES” is selected, the job name is changed and a new job
name is displayed.
– When “NO” is selected, the job name is not changed, and the
process is canceled.
234 of 554

YASKAWA DX100 Specifications

General

Programming Language	Inform III
Compatible Robots	Motoman robots
Operating Temperature	0-45°C
Humidity	20-80% RH (non-condensing)
Protection Class	IP20
Interface	Ethernet
Safety Standards	ANSI/RIA R15.06-1999
Pendant	Available
I/O Capacity	1024 inputs / 1024 outputs
Storage Temperature	-10-60°C
