YASKAWA DX100 Operator's Manual

6 Convenient Functions
6.4 Parallel Shift Job Conversion Function
6-34
155507-1CD
RE-CSO-A037
DX100
6. Select the shift value to be set.
– The number can be entered.
7. Type the shift value using the Numeric keys.
8. Press [ENTER].
– The shift value is set.
9. Display the PARALLEL SHIFT JOB window. Select “EXECUTE”.
– The confirmation dialog box appears when the converted job is not
specified. Select “YES” then the conversion is executed.
– The JOB CONTENT window appears when the conversion is
completed.
274 of 554

YASKAWA DX100 Specifications

General

Programming Language	Inform III
Compatible Robots	Motoman robots
Operating Temperature	0-45°C
Humidity	20-80% RH (non-condensing)
Protection Class	IP20
Interface	Ethernet
Safety Standards	ANSI/RIA R15.06-1999
Pendant	Available
I/O Capacity	1024 inputs / 1024 outputs
Storage Temperature	-10-60°C
