YASKAWA DX100 Operator's Manual

6-71
155507-1CD
RE-CSO-A037
DX100
6 Convenient Functions
6.7 Multi Window Function
3. Press [SHIFT]+[MULTI] keys in step 2 status.
– The general-purpose display area changes to already set pattern in
multi window mode.
311 of 554

YASKAWA DX100 Specifications

General

Programming Language	Inform III
Compatible Robots	Motoman robots
Operating Temperature	0-45°C
Humidity	20-80% RH (non-condensing)
Protection Class	IP20
Interface	Ethernet
Safety Standards	ANSI/RIA R15.06-1999
Pendant	Available
I/O Capacity	1024 inputs / 1024 outputs
Storage Temperature	-10-60°C
