YASKAWA DX100 Operator's Manual

6-105
155507-1CD
RE-CSO-A037
DX100
6 Convenient Functions
6.9 Parameter Setting Function
• JOB SELECT WHEN REMOTE OR PLAY (S2C224)
Refer to section 8.3.0.23 “S2C224: JOB SELECTION AT REMOTE
FUNCTION (PLAY MODE)” on page 8-18.
• I/O-VARIABLE CUSTOMIZE FUNCTION (S2C397)
Refer to section 8.3.0.38 “S2C397: I/O VARIABLE CUSTOMIZE
FUNCTION” on page 8-24.
• GENERAO I/O NAME DISP. ON JOB (S2C544)
Refer to section 8.3.0.46 “S2C544: I/O NAME DISPLAY FUNCTION
FOR JOB” on page 8-30.
• ANTICIPATION FUNCTION (S2C646)
Refer to section 8.8.0.1 “S2C646: ANTICIPATOR FUNCTION” on
page 8-51.
• ALL AXES ANGLE DISP FUNCTION (S2C684 d0 bit)
Refer to section 8.3.0.47 “S2C684:ALL AXES ANGLE DISPLAY
FUNCTION” on page 8-30.
Setting Parameter Status
Permit 0
Prohibit 1
Setting Parameter Status
Invalid 0
Valid 1
Setting Parameter Status
Invalid 0
Valid 1
Setting Parameter Status
Invalid 0
Valid 1
Setting Parameter Status
Invalid 0
Valid 1
345 of 554

YASKAWA DX100 Specifications

General

Programming Language	Inform III
Compatible Robots	Motoman robots
Operating Temperature	0-45°C
Humidity	20-80% RH (non-condensing)
Protection Class	IP20
Interface	Ethernet
Safety Standards	ANSI/RIA R15.06-1999
Pendant	Available
I/O Capacity	1024 inputs / 1024 outputs
Storage Temperature	-10-60°C
