YASKAWA DX100 Operator's Manual

6 Convenient Functions
6.12 Instruction Displaying Color Setting Function
6-122
155507-1CD
RE-CSO-A037
DX100
3. Move the cursor to the instruction to be changed and press [SELECT].
– The list of the candidate colors for the instruction is displayed.
4. Select a color.
– The color of each instruction is fixed.
5. Select JOB window.
– Each instruction is displayed in the selected colors on the job
window.
362 of 554

YASKAWA DX100 Specifications

General

Programming Language	Inform III
Compatible Robots	Motoman robots
Operating Temperature	0-45°C
Humidity	20-80% RH (non-condensing)
Protection Class	IP20
Interface	Ethernet
Safety Standards	ANSI/RIA R15.06-1999
Pendant	Available
I/O Capacity	1024 inputs / 1024 outputs
Storage Temperature	-10-60°C
