YASKAWA DX100 Operator's Manual

7-15
155507-1CD
RE-CSO-A037
DX100
7 External Memory Devices
7.3 Operation Flow
5. Select {EDIT} --> {SETUP FOLDER} under the pull-down menu. Move
the cursor to “AUTO CHANGE” and press [SELECT].
– The initial folder is set in “ROOT FOLDER”.
– “AUTO CHANGE” shows “ON” and the initial folder setting becomes
valid. Subsequently, every time {FD/PC CARD} --> {FOLDER} is
selected, the initial folder that has been set becomes a current
folder.
SUPPLE-
MENT
When the initial folder is missing due to exchange of the
Compact Flash, etc., “ERROR 3360: INVALID FOLDER”
appears when selecting {LOAD}, {SAVE}, {VERIFY},
{DELETE} or {FOLDER} menu from {FD/PC CARD}, and
simultaneously the initial folder becomes invalid. Set “ON”
in “AUTO CHANGE” when the initial folder setting needs to
be valid.
401 of 554

YASKAWA DX100 Specifications

General

Programming Language	Inform III
Compatible Robots	Motoman robots
Operating Temperature	0-45°C
Humidity	20-80% RH (non-condensing)
Protection Class	IP20
Interface	Ethernet
Safety Standards	ANSI/RIA R15.06-1999
Pendant	Available
I/O Capacity	1024 inputs / 1024 outputs
Storage Temperature	-10-60°C
