YASKAWA DX100 Operator's Manual

1 Introduction
1.2 Programming Pendant
1-28
155507-1CD
RE-CSO-A037
DX100
 Delete All Words
Able to delete all registered words.
Delete while the word editing is valid (S2C410=1) during using the
keyboard, or delete the word in the word register screen.
• Delete all registered words. 
Select [Delete All] in the button area.
– The dialog box, which asks {Do you delete all words?}, appears.
Select [Yes].
– The all words are deleted.
56 of 554

YASKAWA DX100 Specifications

General

Programming Language	Inform III
Compatible Robots	Motoman robots
Operating Temperature	0-45°C
Humidity	20-80% RH (non-condensing)
Protection Class	IP20
Interface	Ethernet
Safety Standards	ANSI/RIA R15.06-1999
Pendant	Available
I/O Capacity	1024 inputs / 1024 outputs
Storage Temperature	-10-60°C
