VLAN Configuration Command Set
Assigning VLANs According to Classification Rules
Matrix E1 Series (1G58x-09 and 1H582-xx) Configuration Guide 7-29
Table 7-1 Valid Values for VLAN Classification
data_meaning keywords
data_value keywords
(value applied)
data_ mask
Ethernet-II-Type • 05F6 - FFFF (valid range)
• AppleTalk (809B)
• Banyan-Vines (0BAD)
• DECNET (6003)
• IP (0800 and 0806)
• IPX (8137)
• RARP (8035)
Not applicable.
NOTES: The Matrix E1 allows the use of 3 user defined Ethernet II Type values for
classification into a VLAN. AppleTalk, Banyan-Vines and RARP are considered user
defined, but are listed as options. Additional user defined Ethernet II Type values will
filter (drop) untagged frames as described in Tabl e 7 -2 . IP and DECNET rules also
classify the SNAP frame type.
802.3-SAP • IPX-LLC (E0E0)
• IPX-RAW (FFFF)
• IPX-SNAP (AAAA)
• Netbios (F0F0)
• SNA (0000, 0404, 0808
and 0C0C)
Not applicable.
Table 7-2 Valid Values for VLAN Frame Filtering
NOTE: The parameters in this table DO NOT classify frames into a specific VLAN,
Untagged frames received with any of the data_meanings listed below will be dropped
and not forwarded.
data_meaning data_value(s) data_ mask
IP-TOS (Type of Service) Integer (0 - 255) Not applicable
