VLAN Configuration Command Set
Assigning VLANs According to Classification Rules
7-30 Matrix E1 Series (1G58x-09 and 1H582-xx) Configuration Guide
IP-Protocol-Type • Integer (0 - 255)
• ICMP
• IGMP
• OSPF
• TCP
• UDP
Not applicable.
IPX-COS (Class of Service) Integer (0 - 255) Not applicable.
IPX-Packet-Type
• 0 = Hello-or-SAP
• 1 = RIP
• 2 = Echo-Packet
• 3 = Error-Packet
• 4 = Netware-386-or-SAP
• 5 = Sequenced-Packet-
Protocol
• 16 - 31 = Experimental
Protocols
• 17 = Netware-286
Not applicable.
data_meaning data_value(s) data_ mask
IP Address Group:
Src-IP-Address
Dest-IP-Address
Bil-IP-Address
IP Address in dotted decimal
format: 000.000.000.000
Data mask in dotted decimal
format: 000.000.000.000
NOTE: While the distinction of Source/Destination/Bilateral makes entries with the
same IP Address, Network Number, Port Range, or MAC address unique, only one
entry from this and similar groups in this table may exist for a given address or port
designation. Additional entries will fail.
IPX Network Group:
Src-IPX-Network
Dest-IPX-Network
Bil-IPX-Network
IPX Network Num:
0x00000000
Not applicable.
Table 7-2 Valid Values for VLAN Frame Filtering (Continued)
