Policy Classification Configuration Command Set
Assigning Classification Rules to Policy Profiles
Matrix E1 Series (1G58x-09 and 1H582-xx) Configuration Guide 8-13
IP Address (Bilateral, Source or
Destination):
ipbil
ipsource
ipdest
IP Address in dotted decimal
format:
000.000.000.000
Data mask bits
NOTE: While the distinction of Source/Destination makes entries with the same IP
Address, Network Number, Port Range, or MAC address unique, only one entry from
this and similar groups in this table may exist for a given address or port designation.
Additional entries will fail.
ipproto Protocol field in IP packet -
0 - 255
Not applicable.
iptos Type of Service field in IP
packet:
0 - 255
Not applicable
ipxclass Transmission control (Class
of Service) field in IPX:
0 - 255
Not applicable.
ipxtype IPX packet type field (0 - 255) Not applicable.
IPX Network Address
(Bilateral, Source or
Destination):
ipxbil
ipxsource
ipxdest
IPX Address:
0 - 0xffffffff
Not applicable.
IPX Socket (Bilateral, Source or
Destination):
ipxbilsocket
ipxsourcesocket
ipxdestsocket
IPX Socket Number:
0 - 65535
Not applicable.
Table 8-2 Valid Values for Policy Classification (Continued)
Classification Parameter data_value data_mask
