Port Priority and Classification Configuration Commands

Configuring Priority Classification

Matrix E1 Series (1G58x-09 and 1H582-xx) Configuration Guide 9-21

IP Address Group:

Src-IP-Address

Dest-IP-Address

Bil-IP-Address

IP Address in dotted decimal

format: 000.000.000.000

Data mask in dotted decimal

format: 000.000.000.000

NOTE: While the distinction of Source/Destination/Bilateral makes entries with the

same IP Address, Network Number, Port Range, or MAC address unique, only one

entry from this and similar groups in this table may exist for a given address or port

designation. Additional entries will fail.

IPX Network Group:

Src-IPX-Network

Dest-IPX-Network

Bil-IPX-Network

IPX Network Num:

0x00000000

Not applicable.

UDP Port Group:

Src-UDP-Port

Dest-UDP-Port

Bil-UDP-Port

• Integer (0 - 65535)

• BootP-Client

• BootP-Server

• DNS

• FTP

• FTP-Data

• HTTP

• IMAP2

• IMAP3

• Netbios-Datagram

• Netbios-Name-Server

• Netbios-Sess-Server

• POP3

• RIP

• Smart-Voice-Gateway

• SMTP

• Telnet

• TFTP

Not applicable.

Table 9-1 Valid Values for Priority Classification (Continued)

data_meaning keywords data_value keywords data_ mask
