Port Priority and Classification Configuration Commands
Configuring Priority Classification
9-22 Matrix E1 Series (1G58x-09 and 1H582-xx) Configuration Guide
TCP Port Group:
Src-TCP-Port
Dest-TCP-Port
Bil-TCP-Port
Same selection as for UDP
Port Group
Not applicable.
IPX Socket Group:
Src-IPX-Socket
Dest-IPX-Socket
Bil-IPX-Socket
• Integer (0 - 65535)
• Diagnostics
• IPX-WAN
• NCP
• Netbios
• NLSP
• RIP
• SAP
Not applicable.
MAC Address Group:
Src-MAC-Address
Dest-MAC-Address
Bil-MAC-Address
MAC Address:
00-00-00-00-00-00
Data mask bits
UDP Range Group:
Src-UDP-Range
Dest-UDP-Range
Bil-UDP-Range
Lower boundary of port
range: (0 - 65535)
Upper boundary of port
range:
(0 - 65535)
TCP Range Group:
Src-TCP-Range
Dest-TCP-Range
Bil-TCP-Range
Lower boundary of port
range:
0 - 65535
Upper boundary of port
range:
0 - 65535
Table 9-1 Valid Values for Priority Classification (Continued)
data_meaning keywords data_value keywords data_ mask
