1-2
z Assigning or removing an aggregation member port to or from the isolation group can cause the
other ports in the aggregation group join or leave the isolation group.
z For ports that belong to an aggregation group and an isolation group simultaneously, removing a
port from the aggregation group has no effect on the other ports. That is, the rest ports remain in
the aggregation group and the isolation group.
z Ports that belong to an aggregation group and the isolation group simultaneously are still isolated
after they are removed from the aggregation group (in system view).
z Assigning an isolated port to an aggregation group causes all the ports in the aggregation group on
the local unit to join the isolation group.
z The S3600 series Ethernet switches support cross-device port isolation if IRF fabric is enabled.
By default, the isolation group contains no port.
Examples
# Assign Ethernet 1/0/1 and Ethernet 1/0/2 to the isolation group.
<Sysname> system-view
System View: return to User View with Ctrl+Z.
[Sysname] interface ethernet1/0/1
[Sysname-Ethernet1/0/1] port isolate
[Sysname-Ethernet1/0/1] quit
[Sysname] interface ethernet1/0/2
[Sysname-Ethernet1/0/2] port isolate
After the configuration, packets cannot be exchanged between Ethernet 1/0/1 and Ethernet 1/0/2.
# Remove Ethernet 1/0/1 from the isolation group.
[Sysname-Ethernet1/0/1] undo port isolate
