H3C S3600 Series Command Manual

4-12
Field Description
Flags
Area type flag:
Nssa: NSSA area
NssaDefault: A default route is generated into the NSSA.
NssaNoSummary: ABR is disabled from advertising Type-3 LSAs into
NSSA.
NssaNoRedistribution: Prohibits advertisement of redistributed routes
into NSSA.
Stub: Stub area
StubDefault: A default route is generated into Stub area.
StubNoSummary: ABR is disabled from advertising Type-3 LSAs to
Stub area.
SPF scheduled
SPF scheduled (flag). It indicates what type of route calculation is
being performed.
7/5 translator state
Type-7 LSAs translator state:
Enabled: manually configured Type-7 LSAs translator
Elected: automatically elected Type-7 LSAs translator
Disabled: non-Type-7 LSAs translator
Interface Name of interface belonging to this area
Cost Cost of routes
State
State of the interface state machine:
DOWN: No protocol packet is sent or received on the interface.
Waiting: The interface starts sending and receiving Hello packets and
is trying to identify the (Backup) designated router for the network.
PtoP: The interface sends Hello packets at the interval of
HelloInterval, and tries to establish an adjacency with the peer router.
DR: The router itself is the designated router on the attached network.
BDR: The router itself is the backup designated router on the attached
network.
DROther: The interface is on a network on which another router has
been selected to be the designated router.
Type
Network type of OSPF interface. It can be Broadcast, NBMA, P2MP,
or P2P.
Priority Router priority
Designated Router IP address of a designated router (DR)
Backup Designated Router IP address of a backup designated router (BDR)
Timers
OSPF timers, including
Hello: Hello interval
Dead: Dead interval
Poll: Poll interval
Retransmit: LSA retransmission interval
Transmit Delay Delay time in transmitting LSA
