1-9

Before enabling Web authentication globally, you should first set the IP address of the Web

authentication server.

Examples

# Set the IP address and port number of the Web authentication server to 192.168.0.56 and 80.

<Sysname> system-view

System View: return to User View with Ctrl+Z.

[Sysname] web-authentication web-server ip 192.168.0.56 port 80
