H3C S3600 Series

1-14
Keyword DSCP value in decimal DSCP value in binary
ef
46 101110
If you specify the precedence keyword, you can directly input a value ranging from 0 to 7 or input one of
the keywords listed in
Table 1-9 as IP precedence.
Table 1-9 IP precedence values and the corresponding keywords
Keyword IP Precedence in decimal IP Precedence in binary
routine
0 000
priority
1 001
immediate
2 010
flash
3 011
flash-override
4 100
critical
5 101
internet
6 110
network
7 111
If you specify the tos keyword, you can directly input a value ranging from 0 to 15 or input one of the
keywords listed in
Table 1-10 as the ToS value.
Table 1-10 ToS value and the corresponding keywords
Keyword ToS in decimal ToS in binary
normal
0 0000
min-monetary-cost
1 0001
max-reliability
2 0010
max-throughput
4 0100
min-delay
8 1000
If the protocol type is TCP or UDP, you can also define the information listed in
Table 1-11.
