KLA Tencor P-16+ - Figure 4.21 Sequence Editor with die Grid Menu

XY View Screen - Using Die Grid Navigation (Optional Feature, P-16+ only) KLA-Tencor P-16+ / P-6 User’s Guide
4-26 KLA-Tencor Confidential 0142530-000 AB
3/13/09
3. Click Load to display the Load Die Grid dialog box. (See Figure 4.22.)
Figure 4.21 Sequence Editor with Die Grid Menu
Step 2 Click Die
Grid
to display its
menu.
Step 3 Click
Load... to display
the Load Die Grid
dialog box.
