TP-Link T2600G Series User Manual

Managing System SDM Template Configuration
User Guide
71
Next Template Displays the template that will be effective after the reboot.
Select Next
Template
Select the template that will be effective after the next reboot.
Default: Select the template of default. It gives balance to the IP ACL rules and MAC
ACL rules.
EnterpriseV4: Select the template of enterpriseV4. It maximizes system resources
for IP ACL rules and MAC ACL rules.
EnterpriseV6: Select the template of enterpriseV6. It allocates resources to IPv6
ACL rules.
The Template Table displays the resources allocation of each template. The values are
different for different switch models.
SDM Template Displays the name of the templates.
IP ACL Rules Displays the number of IP ACL Rules including Layer 3 ACL Rules and Layer 4 ACL
Rules.
MAC ACL Rules Displays the number of Layer 2 ACL Rules.
Combined ACL
Rules
Displays the number of combined ACL rules.
IPv6 ACL Rules Displays the number of IPv6 ACL rules.
IPv4 Source Guard
Entries
Displays the number of IPv4 source guard entries.
Note: IPv4 Source Guard Entries is only available for T2600G-18TS.
IPv6 Source Guard
Entries
Displays the number of IPv6 source guard entries.
Packet Content
ACL Rules
Displays the number of packet content ACL rules.
Note: Packet Content ACL Rules is not available for T2600G-18TS.
7.2 Using the CLI
Follow these steps to configure the SDM template:
Step 1 configure
Enter global configuration mode.

TP-Link T2600G Series Specifications

General

Model	T2600G Series
Layer	Layer 2+
Type	Managed
Uplink Ports	4 x Gigabit SFP slots
VLAN	4K VLANs
QoS	8 priority queues
Management	Web-based GUI, CLI, SNMP, RMON
Standards and Protocols	IEEE 802.3i, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3z, IEEE 802.3ad, IEEE 802.3x, IEEE 802.1d, IEEE 802.1s, IEEE 802.1w, IEEE 802.1q, IEEE 802.1p, IEEE 802.3af, IEEE 802.3at
Interface	RJ45
L2 Features	STP, RSTP, MSTP, LACP, IGMP Snooping
L3 Features	Static Routing
Security	802.1X, Port Security, DHCP Snooping, IP Source Guard, DoS Defend, ARP Inspection, SSH, SSL, ACL
MAC Address Table	16K
Jumbo Frame	9KB
Operating Temperature	0°C to 40°C
Storage Temperature	-40°C to 70°C
Operating Humidity	10% to 90% RH non-condensing
Storage Humidity	5% to 90% non-condensing
