TP-Link T2600G Series User Manual

User Guide 720
Configuring AAA Overview
1
Overview
AAA stands for authentication, authorization and accounting. On TP-Link switches,
this feature is mainly used to authenticate the users trying to log in to the switch or get
administrative privileges. The administrator can create guest accounts and an Enable
password for other users. The guests do not have administrative privileges without the
Enable password provided.
AAA provides a safe and efficient authentication method. The authentication can be
processed locally on the switch or centrally on the RADIUS/TACACS+ server(s). As the
following figure shows, the network administrator can centrally configure the management
accounts of the switches on the RADIUS server and use this server to authenticate the
users trying to access the switch or get administrative privileges.
Figure 1-1 Network Topology of AAA
RADIUS Server
Users Switches

TP-Link T2600G Series Specifications

General

Model	T2600G Series
Layer	Layer 2+
Type	Managed
Uplink Ports	4 x Gigabit SFP slots
VLAN	4K VLANs
QoS	8 priority queues
Management	Web-based GUI, CLI, SNMP, RMON
Standards and Protocols	IEEE 802.3i, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3z, IEEE 802.3ad, IEEE 802.3x, IEEE 802.1d, IEEE 802.1s, IEEE 802.1w, IEEE 802.1q, IEEE 802.1p, IEEE 802.3af, IEEE 802.3at
Interface	RJ45
L2 Features	STP, RSTP, MSTP, LACP, IGMP Snooping
L3 Features	Static Routing
Security	802.1X, Port Security, DHCP Snooping, IP Source Guard, DoS Defend, ARP Inspection, SSH, SSL, ACL
MAC Address Table	16K
Jumbo Frame	9KB
Operating Temperature	0°C to 40°C
Storage Temperature	-40°C to 70°C
Operating Humidity	10% to 90% RH non-condensing
Storage Humidity	5% to 90% non-condensing
