TP-Link T2600G Series User Manual

Configuring 802.1x 802.1x Configuration
User Guide
761
Switch#configure
Switch(config)#dot1x system-auth-control
Switch(config)#dot1x auth-protocol pap
Switch(config)#show dot1x global
802.1X State: Enabled
Authentication Protocol: PAP
Handshake State: Enabled
802.1X Accounting State: Disabled
802.1X VLAN Assignment State: Disabled
Switch(config)#end
Switch#copy running-config startup-config
2.2.3 Configuring 802.1x on Ports
Follow these steps to configure the port:
Step 1 configure
Enter global configuration mode.
Step 2 interface {fastEthernet
port | range fastEthernet port-list | gigabitEthernet port | range
gigabitEthernet
port-list | ten-gigabitEthernet port | range ten-gigabitEthernet port-list }
Enter interface configuration mode.
port: Enter the ID of the port to be configured.
Step 3 dot1x
Enable 802.1x authentication for the port.
Step 4 dot1x mab
Enable the MAB (MAC-Based Authentication Bypass) feature for the port.
With MAB feature enabled, the switch automatically sends the authentication server
a RADIUS access request frame with the client’s MAC address as the username and
password. It is also necessary to configure the RADIUS server with the client’s information
for authentication. You can enable this feature on IEEE 802.1x ports connected to devices
without 802.1x capability. For example, most printers, IP phones and fax machines do not
have 802.1x capability.
Note: MAB cannot work if Guest VLAN is enabled.

TP-Link T2600G Series Specifications

General

Model	T2600G Series
Layer	Layer 2+
Type	Managed
Uplink Ports	4 x Gigabit SFP slots
VLAN	4K VLANs
QoS	8 priority queues
Management	Web-based GUI, CLI, SNMP, RMON
Standards and Protocols	IEEE 802.3i, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3z, IEEE 802.3ad, IEEE 802.3x, IEEE 802.1d, IEEE 802.1s, IEEE 802.1w, IEEE 802.1q, IEEE 802.1p, IEEE 802.3af, IEEE 802.3at
Interface	RJ45
L2 Features	STP, RSTP, MSTP, LACP, IGMP Snooping
L3 Features	Static Routing
Security	802.1X, Port Security, DHCP Snooping, IP Source Guard, DoS Defend, ARP Inspection, SSH, SSL, ACL
MAC Address Table	16K
Jumbo Frame	9KB
Operating Temperature	0°C to 40°C
Storage Temperature	-40°C to 70°C
Operating Humidity	10% to 90% RH non-condensing
Storage Humidity	5% to 90% non-condensing
