TP-Link T2600G Series User Manual

Configuring Routing IPv6 Static Routing Configuration
User Guide
525
3
IPv6 Static Routing Configuration
3.1 Using the GUI
Choose the menu L3 FEATURES > Static Routing > IPv6 Static Routing > IPv6 Static
Routing Table and click
to load the following page.
Figure 3-1 Configuring the IPv6 Static Routing
Configure the corresponding parameters to add an IPv6 static routing entry. Then click
Create.
IPv6 Address Specify the destination IPv6 address of the packets.
Prefix Length Specify the prefix length of the IPv6 address.
Next Hop Specify the IPv6 gateway address to which the packet should be sent next.
Distance Specify the administrative distance, which is the trust rating of a routing entry. A
higher value means a lower trust rating. Among the routes to the same destination,
the route with the lowest distance value will be recorded in the IPv6 routing table.
The valid value ranges from 1 to 255 and the default value is 1

TP-Link T2600G Series Specifications

General

Model	T2600G Series
Layer	Layer 2+
Type	Managed
Uplink Ports	4 x Gigabit SFP slots
VLAN	4K VLANs
QoS	8 priority queues
Management	Web-based GUI, CLI, SNMP, RMON
Standards and Protocols	IEEE 802.3i, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3z, IEEE 802.3ad, IEEE 802.3x, IEEE 802.1d, IEEE 802.1s, IEEE 802.1w, IEEE 802.1q, IEEE 802.1p, IEEE 802.3af, IEEE 802.3at
Interface	RJ45
L2 Features	STP, RSTP, MSTP, LACP, IGMP Snooping
L3 Features	Static Routing
Security	802.1X, Port Security, DHCP Snooping, IP Source Guard, DoS Defend, ARP Inspection, SSH, SSL, ACL
MAC Address Table	16K
Jumbo Frame	9KB
Operating Temperature	0°C to 40°C
Storage Temperature	-40°C to 70°C
Operating Humidity	10% to 90% RH non-condensing
Storage Humidity	5% to 90% non-condensing
