TP-Link T2600G Series User Manual

User Guide 1086
Diagnosing the Device & Network Diagnosing the Network
2
Diagnosing the Network
The network diagnostics feature provides Ping testing and Tracert testing. You can test
connectivity to remote hosts, or to the gateways from the switch to the destination.
With Network Diagnostics, you can:
■ Troubleshoot with Ping testing.
■ Troubleshoot with Tracert testing.
2.1 Using the GUI
2.1.1 Troubleshooting with Ping Testing
You can use the Ping tool to test connectivity to remote hosts.
Choose the menu MAINTENANCE > Network Diagnostics > Ping to load the following
page.
Figure 2-1 Troubleshooting with Ping Testing

TP-Link T2600G Series Specifications

General

Model	T2600G Series
Layer	Layer 2+
Type	Managed
Uplink Ports	4 x Gigabit SFP slots
VLAN	4K VLANs
QoS	8 priority queues
Management	Web-based GUI, CLI, SNMP, RMON
Standards and Protocols	IEEE 802.3i, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3z, IEEE 802.3ad, IEEE 802.3x, IEEE 802.1d, IEEE 802.1s, IEEE 802.1w, IEEE 802.1q, IEEE 802.1p, IEEE 802.3af, IEEE 802.3at
Interface	RJ45
L2 Features	STP, RSTP, MSTP, LACP, IGMP Snooping
L3 Features	Static Routing
Security	802.1X, Port Security, DHCP Snooping, IP Source Guard, DoS Defend, ARP Inspection, SSH, SSL, ACL
MAC Address Table	16K
Jumbo Frame	9KB
Operating Temperature	0°C to 40°C
Storage Temperature	-40°C to 70°C
Operating Humidity	10% to 90% RH non-condensing
Storage Humidity	5% to 90% non-condensing
