TP-Link T2600G Series User Manual

User Guide 352
Configuring Layer 2 Multicast Viewing Multicast Snooping Information
Report Packets
(v2)
Displays the number of IGMPv2 report packets received by the port.
Report Packets
(v3)
Displays the number of IGMPv3 report packets received by the port.
Leave Packets Displays the number of leave packets received by the port.
Error Packets Displays the number of error packets received by the port.
6.1.3 Viewing IPv6 Multicast Table
Choose the menu L2 FEATURES > Multicast > Multicast Info > IPv6 Multicast Table to
load the following page
:
Figure 6-3 IPv6 Multicast Table
The multicast IP address table shows all valid Multicast IP-VLAN-Port entries:
Multicast IP Displays the multicast source IP address.
VLAN ID Displays the ID of the VLAN the multicast group belongs to.
Source Displays the source of the multicast entry.
MLD Snooping: The multicast entry is learned by IGMP Snooping.
Type Displays how the multicast entry is generated.
Dynamic: The entry is dynamically learned. All the member ports are dynamically
added to the multicast group.
Static: The entry is manually added. All the member ports are manually added to the
multicast group.
Mix: The entry is dynamically learned (manually learned), and some of the member
ports are manually added (dynamically added) to the multicast group.
Forward Port All ports in the multicast group, including router ports and member ports.

TP-Link T2600G Series Specifications

General

Model	T2600G Series
Layer	Layer 2+
Type	Managed
Uplink Ports	4 x Gigabit SFP slots
VLAN	4K VLANs
QoS	8 priority queues
Management	Web-based GUI, CLI, SNMP, RMON
Standards and Protocols	IEEE 802.3i, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3z, IEEE 802.3ad, IEEE 802.3x, IEEE 802.1d, IEEE 802.1s, IEEE 802.1w, IEEE 802.1q, IEEE 802.1p, IEEE 802.3af, IEEE 802.3at
Interface	RJ45
L2 Features	STP, RSTP, MSTP, LACP, IGMP Snooping
L3 Features	Static Routing
Security	802.1X, Port Security, DHCP Snooping, IP Source Guard, DoS Defend, ARP Inspection, SSH, SSL, ACL
MAC Address Table	16K
Jumbo Frame	9KB
Operating Temperature	0°C to 40°C
Storage Temperature	-40°C to 70°C
Operating Humidity	10% to 90% RH non-condensing
Storage Humidity	5% to 90% non-condensing
