TP-Link T2600G Series User Manual

RMON Configurations
User Guide
1055
5
RMON Configurations
With RMON configurations, you can:
■
Configuring the Statistics group.
■
Configuring the History group.
■
Configuring the Event group.
■
Configuring the Alarm group.
Configuration Guidelines
To ensure that the NMS receives notifications normally, complete configurations of SNMP
and SNMP Notification before configuring RMON.
5.1 Using the GUI
5.1.1 Configuring the Statistics Group
Choose the menu MAINTENANCE > SNMP > RMON > Statistics and click to load
the following page.
Figure 5-1 Creating a Statistics Entry
Follow these steps to configure the Statistics group:
1) Specify the entry index, the port to be monitored, and the owner name of the entry. Set
the entry as Valid or Under Creation.
Index Enter the index of the entry.
Port Specify an Ethernet port to be monitored in the entry. You can click Choose
to choose a port from the list or manually enter the port number, for example,
1/0/1 in the input box.
Owner Enter the owner name of the entry with1 to 16 characters.

TP-Link T2600G Series Specifications

General

Model	T2600G Series
Layer	Layer 2+
Type	Managed
Uplink Ports	4 x Gigabit SFP slots
VLAN	4K VLANs
QoS	8 priority queues
Management	Web-based GUI, CLI, SNMP, RMON
Standards and Protocols	IEEE 802.3i, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3z, IEEE 802.3ad, IEEE 802.3x, IEEE 802.1d, IEEE 802.1s, IEEE 802.1w, IEEE 802.1q, IEEE 802.1p, IEEE 802.3af, IEEE 802.3at
Interface	RJ45
L2 Features	STP, RSTP, MSTP, LACP, IGMP Snooping
L3 Features	Static Routing
Security	802.1X, Port Security, DHCP Snooping, IP Source Guard, DoS Defend, ARP Inspection, SSH, SSL, ACL
MAC Address Table	16K
Jumbo Frame	9KB
Operating Temperature	0°C to 40°C
Storage Temperature	-40°C to 70°C
Operating Humidity	10% to 90% RH non-condensing
Storage Humidity	5% to 90% non-condensing
