Configuring VLAN-VPN Flexible VLAN-VPN Configuration
User Guide
231
Figure 3-2 Create VLAN Mapping Entry
Port For T2600G-28TS/T2600G-28TS-DC/T2600G-28MPS/T2600G-28SQ/T2600G-
52TS, choose a UNI port to enable VLAN mapping.
For T2600G-18TS, choose a NNI port to enable VLAN mapping.
C VLAN Specify the customer VLAN of the UNI port by entering the VLAN ID or VLAN
Name.
SP VLAN Specify the ISP VLAN of the UNI port by entering the VLAN ID or VLAN Name.
Description Give a description to identify the VLAN Mapping.
3) Click Create.
3.2 Using the CLI
Follow these steps to configure flexible VLAN-VPN:
Step 1 configure
Enter global configuration mode.
Step 2 dot1q-tunnel mapping
Enable VLAN mapping globally.
Step 3 interface {fastEthernet
port
| range fastEthernet
port-list
| gigabitEthernet
port
| range
gigabitEthernet
port-list
| ten-gigabitEthernet
port
| range ten-gigabitEthernet
port-list
|
port-channel
port-channel-id
| range port-channel
port-channel-list
}
For T2600G-28TS/T2600G-28TS-DC/T2600G-28MPS/T2600G-28SQ/T2600G-52TS,
choose a UNI port to enable VLAN mapping.
For T2600G-18TS, choose a NNI port to enable VLAN mapping.
