TP-Link T2600G Series User Manual

Notification Configurations
User Guide
1039
3
Notification Configurations
With Notification enabled, the switch can send notifications to the NMS about important
events relating to the device’s operation. This facilitates the monitoring and management
of the NMS.
To configure SNMP notification, follow these steps:
1) Configure the information of NMS hosts.
2) Enable SNMP traps.
Configuration Guidelines
To guarantee the communication between the switch and the NMS, ensure the switch and
the NMS can reach one another.
3.1 Using the GUI
3.1.1 Configuring the Information of NMS Hosts
Choose the menu MAINTENANCE > SNMP > Notification > Notification Config and click
to load the following page.
Figure 3-1 Adding an NMS Host
Follow these steps to add an NMS host:
1) Choose the IP mode according to the network environment, and specify the IP address
of the NMS host and the UDP port that receives notifications.

TP-Link T2600G Series Specifications

General

Model	T2600G Series
Layer	Layer 2+
Type	Managed
Uplink Ports	4 x Gigabit SFP slots
VLAN	4K VLANs
QoS	8 priority queues
Management	Web-based GUI, CLI, SNMP, RMON
Standards and Protocols	IEEE 802.3i, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3z, IEEE 802.3ad, IEEE 802.3x, IEEE 802.1d, IEEE 802.1s, IEEE 802.1w, IEEE 802.1q, IEEE 802.1p, IEEE 802.3af, IEEE 802.3at
Interface	RJ45
L2 Features	STP, RSTP, MSTP, LACP, IGMP Snooping
L3 Features	Static Routing
Security	802.1X, Port Security, DHCP Snooping, IP Source Guard, DoS Defend, ARP Inspection, SSH, SSL, ACL
MAC Address Table	16K
Jumbo Frame	9KB
Operating Temperature	0°C to 40°C
Storage Temperature	-40°C to 70°C
Operating Humidity	10% to 90% RH non-condensing
Storage Humidity	5% to 90% non-condensing
