TP-Link T2600G Series User Manual

User Guide 954
Mirroring Traffic Mirroring
1
Mirroring
You can analyze network traffic and troubleshoot network problems using Mirroring.
Mirroring allows the switch to send a copy of the traffic that passes through specified
sources (ports, LAGs or the CPU) to a destination port. It does not affect the switching of
network traffic on source ports, LAGs or the CPU.
1.1 Using the GUI
Choose the menu MAINTENANCE > Mirroring to load the following page.
Figure 1-1 Port Mirroring Session List
The above page displays a mirroring session, and no more session can be created. Click
Edit to configure this mirroring session on the following page.

TP-Link T2600G Series Specifications

General

Model	T2600G Series
Layer	Layer 2+
Type	Managed
Uplink Ports	4 x Gigabit SFP slots
VLAN	4K VLANs
QoS	8 priority queues
Management	Web-based GUI, CLI, SNMP, RMON
Standards and Protocols	IEEE 802.3i, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3z, IEEE 802.3ad, IEEE 802.3x, IEEE 802.1d, IEEE 802.1s, IEEE 802.1w, IEEE 802.1q, IEEE 802.1p, IEEE 802.3af, IEEE 802.3at
Interface	RJ45
L2 Features	STP, RSTP, MSTP, LACP, IGMP Snooping
L3 Features	Static Routing
Security	802.1X, Port Security, DHCP Snooping, IP Source Guard, DoS Defend, ARP Inspection, SSH, SSL, ACL
MAC Address Table	16K
Jumbo Frame	9KB
Operating Temperature	0°C to 40°C
Storage Temperature	-40°C to 70°C
Operating Humidity	10% to 90% RH non-condensing
Storage Humidity	5% to 90% non-condensing
