TP-Link T2600G Series User Manual

User Guide 608
Configuring ARP ARP Configurations
Type Displays the type of an ARP entry.
Static: The entry is added manually and will always remain the same.
Dynamic: The entry that will be deleted after the aging time leased. The default aging
time value is 600 seconds. If you want to change the aging time, you can use the CLI
to configure it.
2.1.2 Adding Static ARP Entries Manually
You can add desired static ARP entries by mannually specifying the IP addresses and MAC
addresses.
Choose the menu L3 FEATURES > ARP > Static ARP and click
to load the
following page.
Figure 2-2 Adding Static ARP Entries
Enter the IP address and MAC address, then click Create.
IP address Specify the IP address of the static ARP entry.
MAC address Specify the MAC address.of the static ARP entry.
2.1.3 Configuring Gratuitous ARP
Choose the menu L3 FEATURES > ARP > Gratuitous ARP to load the following page.

TP-Link T2600G Series Specifications

General

Model	T2600G Series
Layer	Layer 2+
Type	Managed
Uplink Ports	4 x Gigabit SFP slots
VLAN	4K VLANs
QoS	8 priority queues
Management	Web-based GUI, CLI, SNMP, RMON
Standards and Protocols	IEEE 802.3i, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3z, IEEE 802.3ad, IEEE 802.3x, IEEE 802.1d, IEEE 802.1s, IEEE 802.1w, IEEE 802.1q, IEEE 802.1p, IEEE 802.3af, IEEE 802.3at
Interface	RJ45
L2 Features	STP, RSTP, MSTP, LACP, IGMP Snooping
L3 Features	Static Routing
Security	802.1X, Port Security, DHCP Snooping, IP Source Guard, DoS Defend, ARP Inspection, SSH, SSL, ACL
MAC Address Table	16K
Jumbo Frame	9KB
Operating Temperature	0°C to 40°C
Storage Temperature	-40°C to 70°C
Operating Humidity	10% to 90% RH non-condensing
Storage Humidity	5% to 90% non-condensing
