TP-Link T2600G Series User Manual

Configuring IPv6 IMPB ND Detection Configuration
User Guide
893
3
ND Detection Configuration
To complete ND Detection configuration, follow these steps:
1) Add IPv6-MAC Binding entries.
2) Enable ND Detection.
3) Configure ND Detection on ports.
4) View ND statistics.
3.1 Using the GUI
3.1.1 Adding IPv6-MAC Binding Entries
The ND Detection feature allows the switch to detect the ND packets based on the
binding entries in the IPv6-MAC Binding Table and filter out the illegal ND packets. Before
configuring ND Detection, complete IPv6-MAC Binding configuration. For details, refer to
IPv6-MAC Binding Configuration.
3.1.2 Enabling ND Detection
Choose the menu SECURITY > IPv6 IMPB > ND Detection > Global Config to load the
following page.
Figure 3-1 ND Detection Global Config
Follow these steps to enable ND Detection:
1) In the Global Config section, enable ND Detection and configure the related
parameters. Click Apply.
ND Detection Enable or disable ND Detection globally.
2) In the VLAN Config section, enable ND Detection on the selected VLANs. Click Apply.

TP-Link T2600G Series Specifications

General

Model	T2600G Series
Layer	Layer 2+
Type	Managed
Uplink Ports	4 x Gigabit SFP slots
VLAN	4K VLANs
QoS	8 priority queues
Management	Web-based GUI, CLI, SNMP, RMON
Standards and Protocols	IEEE 802.3i, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3z, IEEE 802.3ad, IEEE 802.3x, IEEE 802.1d, IEEE 802.1s, IEEE 802.1w, IEEE 802.1q, IEEE 802.1p, IEEE 802.3af, IEEE 802.3at
Interface	RJ45
L2 Features	STP, RSTP, MSTP, LACP, IGMP Snooping
L3 Features	Static Routing
Security	802.1X, Port Security, DHCP Snooping, IP Source Guard, DoS Defend, ARP Inspection, SSH, SSL, ACL
MAC Address Table	16K
Jumbo Frame	9KB
Operating Temperature	0°C to 40°C
Storage Temperature	-40°C to 70°C
Operating Humidity	10% to 90% RH non-condensing
Storage Humidity	5% to 90% non-condensing
