TP-Link T2600G Series User Manual

Diagnosing the Device & Network Diagnosing the Network
User Guide
1089
2.2.2 Configuring the Tracert Test
On privileged EXEC mode, you can use the following command to test the connectivity
between the switch and routers along the path from the source to the destination:
tracert [ ip | ipv6 ] ip_addr [ maxHops ]
Test the connectivity of the gateways along the path from the source to the destination.
ip: The type of the IP address for tracert test should be IPv4.
ipv6: The type of the IP address for tracert test should be IPv6.
ip_addr: Enter the IP address of the destination device. If the parameter ip/ipv6 is not selected, both IPv4
and IPv6 addresses are supported, such as 192.168.0.100 or fe80::1234.
maxHops : Specify the maximum number of the route hops the test data can pass though. The range is 1 to
30 hops; the default is 4 hops.
The following example shows how to test the connectivity between the switch and the
network device with the IP address 192.168.0.100. Set the maxhops as 2:
Switch#tracert 192.168.0.100 2
Tracing route to 192.168.0.100 over a maximum of 2 hops
1 8 ms 1 ms 2 ms 192.168.1.1
2 2 ms 2 ms 2 ms 192.168.0.100
Trace complete.

TP-Link T2600G Series Specifications

General

Model	T2600G Series
Layer	Layer 2+
Type	Managed
Uplink Ports	4 x Gigabit SFP slots
VLAN	4K VLANs
QoS	8 priority queues
Management	Web-based GUI, CLI, SNMP, RMON
Standards and Protocols	IEEE 802.3i, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3z, IEEE 802.3ad, IEEE 802.3x, IEEE 802.1d, IEEE 802.1s, IEEE 802.1w, IEEE 802.1q, IEEE 802.1p, IEEE 802.3af, IEEE 802.3at
Interface	RJ45
L2 Features	STP, RSTP, MSTP, LACP, IGMP Snooping
L3 Features	Static Routing
Security	802.1X, Port Security, DHCP Snooping, IP Source Guard, DoS Defend, ARP Inspection, SSH, SSL, ACL
MAC Address Table	16K
Jumbo Frame	9KB
Operating Temperature	0°C to 40°C
Storage Temperature	-40°C to 70°C
Operating Humidity	10% to 90% RH non-condensing
Storage Humidity	5% to 90% non-condensing
