TP-Link T2600G Series User Manual

User Guide 206
Configuring Protocol VLAN Protocol VLAN Configuration
The following example shows how to create an IPv6 protocol template:
Switch#configure
Switch(config)#protocol-vlan template name IPv6 frame ether_2 ether-type 86dd
Switch(config)#show protocol-vlan template
Index Protocol Name Protocol Type
------- ----------------- --------------------------------
1 IP EthernetII ether-type 0800
2 ARP EthernetII ether-type 0806
3 RARP EthernetII ether-type 8035
4 IPX SNAP ether-type 8137
5 AT SNAP ether-type 809B
6 IPv6 EthernetII ether-type 86DD
Switch(config)#end
Switch#copy running-config startup-config
2.2.3 Configuring Protocol VLAN
Follow these steps to configure protocol VLAN:
Step 1 configure
Enter global configuration mode.
Step 2 show protocol-vlan template
Check the index of each protocol template.
Step 3 protocol-vlan vlan
vid priority priority template index
Bind the protocol template to the VLAN.
vid : Enter the ID number of the 802.1Q VLAN that will be bound to the Protocol VLAN.
priority : Specify the 802.1p priority for the packets that belong to the protocol VLAN. The
switch will determine the forwarding sequence according this value. The packets with larger
value of 802.1p priority have the higher priority.
index : Specify the protocol template index.
Step 4 show protocol-vlan vlan
Check the protocol VLAN index (entry-id) of each protocol group.

TP-Link T2600G Series Specifications

General

Model	T2600G Series
Layer	Layer 2+
Type	Managed
Uplink Ports	4 x Gigabit SFP slots
VLAN	4K VLANs
QoS	8 priority queues
Management	Web-based GUI, CLI, SNMP, RMON
Standards and Protocols	IEEE 802.3i, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3z, IEEE 802.3ad, IEEE 802.3x, IEEE 802.1d, IEEE 802.1s, IEEE 802.1w, IEEE 802.1q, IEEE 802.1p, IEEE 802.3af, IEEE 802.3at
Interface	RJ45
L2 Features	STP, RSTP, MSTP, LACP, IGMP Snooping
L3 Features	Static Routing
Security	802.1X, Port Security, DHCP Snooping, IP Source Guard, DoS Defend, ARP Inspection, SSH, SSL, ACL
MAC Address Table	16K
Jumbo Frame	9KB
Operating Temperature	0°C to 40°C
Storage Temperature	-40°C to 70°C
Operating Humidity	10% to 90% RH non-condensing
Storage Humidity	5% to 90% non-condensing
